Manages MIDI music playback with Win32 MIDI streaming for the LEGO Island engine. More...

#include <mxmusicmanager.h>

Inheritance diagram for MxMusicManager:

[legend]

Collaboration diagram for MxMusicManager:

[legend]

Public Member Functions
	MxMusicManager ()
	Constructs an instance and initializes member data. More...

	~MxMusicManager () override
	Destructor, ensures proper cleanup of resources and MIDI deinitialization. More...

void	Destroy () override
	Releases all resources and stops streaming. More...

void	SetVolume (MxS32 p_volume) override
	Sets the music playback volume, taking into account multiplier for overall gain adjustment. More...

virtual MxResult	Create (MxU32 p_frequencyMS, MxBool p_createThread)
	Initializes and starts MIDI playback. More...

MxBool	GetMIDIInitialized ()
	Checks if the MIDI system is currently initialized and ready. More...

void	GetMIDIVolume (DWORD &p_volume)
	Retrieves the current hardware MIDI out volume. More...

MxResult	ResetStream ()
	Schedules and streams the next chunk of MIDI data; handles buffer looping and completion. More...

void	ResetBuffer ()
	Resets the MIDI buffer to the starting offset and sets the buffer size to the full stream. More...

MxResult	InitializeMIDI (MxU8 *p_data, MxS32 p_loopCount)
	Initializes streaming for a MIDI data buffer and begins playback. More...

void	DeinitializeMIDI ()
	Stops playback and releases all MIDI streaming resources. More...

void	SetMultiplier (MxS32 p_multiplier)
	Sets the volume multiplier for scaling volume output. More...

Public Member Functions inherited from MxAudioManager
	MxAudioManager ()
	[AI] Constructs the audio manager and initializes default volume. More...

	~MxAudioManager () override
	[AI] Destructs the audio manager and handles cleanup of resources. More...

MxResult	Create () override
	[AI] Initializes audio subsystem resources and registers an instance for global audio management. More...

void	Destroy () override
	[AI] Tears down the audio subsystem instance and unregisters it from global management. More...

virtual MxS32	GetVolume ()
	[AI] Gets the current global audio volume. More...

virtual void	SetVolume (MxS32 p_volume)
	[AI] Sets the current global audio volume. More...

Public Member Functions inherited from MxMediaManager
	MxMediaManager ()
	[AI] Constructor. More...

	~MxMediaManager () override
	[AI] Destructor. More...

MxResult	Tickle () override
	[AI] Called by the tickle manager to step through and update all presenters, and process their output data. More...

virtual MxResult	Create ()
	[AI] Allocates and initializes the internal presenter list for this manager, ensuring thread safety. More...

virtual void	Destroy ()
	[AI] Destroys all registered presenters and resets the internal state, ensuring safe resource disposal. More...

virtual void	RegisterPresenter (MxPresenter &p_presenter)
	[AI] Register a new presenter for tickle management and playback coordination. More...

virtual void	UnregisterPresenter (MxPresenter &p_presenter)
	[AI] Remove a presenter from tickle and managed output lists. More...

virtual void	StopPresenters ()
	[AI] Stops/ends the action on all registered presenters, typically halting all playback and output. More...

MxResult	Init ()
	[AI] Initializes all internal members to their default values. More...

Public Member Functions inherited from MxCore
	MxCore ()
	[AI] Constructs a new MxCore object and assigns it a unique id. More...

virtual	~MxCore ()
	[AI] Virtual destructor. Required for correct polymorphic cleanup in derived classes. More...

virtual MxLong	Notify (MxParam &p_param)
	[AI] Virtual callback notification mechanism. More...

virtual MxResult	Tickle ()
	[AI] Called by tickle managers to allow the object to update itself. More...

virtual const char *	ClassName () const
	[AI] Returns the runtime class name of this object. More...

virtual MxBool	IsA (const char *p_name) const
	[AI] Checks whether this object's class type or parents match the given name. More...

MxU32	GetId ()
	[AI] Gets the unique (per-process) id assigned to this object instance. More...

Protected Member Functions
void	Init ()
	Initializes multipliers and buffer with default values; called from constructor/Destroy. More...

void	InitData ()
	Initializes and zeros all associated MIDI-related member data. More...

Protected Member Functions inherited from MxAudioManager
void	Init ()
	[AI] Initializes audio manager state, setting default volume and other relevant fields. More...

Additional Inherited Members
Protected Attributes inherited from MxAudioManager
MxS32	m_volume
	[AI] Holds the current global audio volume for the game. More...

Protected Attributes inherited from MxMediaManager
MxPresenterList *	m_presenters
	[AI] Pointer to list of currently registered (active) presenters. More...

MxThread *	m_thread
	[AI] Optional pointer to a worker thread used for media dispatch/IO (if multi-threaded operation is used, otherwise NULL). More...

MxCriticalSection	m_criticalSection
	[AI] Critical section object used for guarding access to the presenter list and internal members for thread safety. More...

Detailed Description

Manages MIDI music playback with Win32 MIDI streaming for the LEGO Island engine.

[AI] Forward declaration for the music manager controlling soundtrack playback and music resources.

[AI]

MxMusicManager inherits from MxAudioManager and extends it with MIDI handling, including streaming, looping, MIDI hardware initialization, and volume/multiplier mixing controls. Designed for music playback, including looping, dynamic volume control, and integration with audio tickling threads for timing. [AI]

Definition at line 16 of file mxmusicmanager.h.

Constructor & Destructor Documentation

◆ MxMusicManager()

MxMusicManager::MxMusicManager ( )

Constructs an instance and initializes member data.

[AI]

Definition at line 12 of file mxmusicmanager.cpp.

◆ ~MxMusicManager()

MxMusicManager::~MxMusicManager ( )

override

Destructor, ensures proper cleanup of resources and MIDI deinitialization.

[AI]

Definition at line 18 of file mxmusicmanager.cpp.

Member Function Documentation

◆ Create()

MxResult MxMusicManager::Create	(	MxU32	p_frequencyMS,
		MxBool	p_createThread
	)

virtual

Initializes and starts MIDI playback.

[AI]

Optionally creates a tickle thread for timing, or registers this as a tickle client with the given tick interval (in ms). [AI]

Parameters

p_frequencyMS	Interval in ms between tickle updates. [AI]
p_createThread	If TRUE, creates a separate MxTickleThread for streaming. If FALSE, uses global TickleManager. [AI]

Returns: SUCCESS on initialization, FAILURE otherwise. [AI]

Definition at line 142 of file mxmusicmanager.cpp.

◆ DeinitializeMIDI()

void MxMusicManager::DeinitializeMIDI ( )

Stops playback and releases all MIDI streaming resources.

[AI]

Restores hardware volume to original, stops stream, unprepares header, and deletes buffer data. [AI]

Definition at line 279 of file mxmusicmanager.cpp.

◆ Destroy()

void MxMusicManager::Destroy ( )

overridevirtual

Releases all resources and stops streaming.

[AI]

Disables music playback and unregisters the tickle client. Called automatically from the destructor with p_fromDestructor=TRUE, or manually with p_fromDestructor=FALSE. [AI]

Parameters

p_fromDestructor TRUE if called from destructor (does not call base class Destroy if true). [AI]

Reimplemented from MxAudioManager.

Definition at line 177 of file mxmusicmanager.cpp.

◆ GetMIDIInitialized()

MxBool MxMusicManager::GetMIDIInitialized ( )

inline

Checks if the MIDI system is currently initialized and ready.

[AI]

Returns: TRUE if initialized, FALSE otherwise. [AI]

Definition at line 54 of file mxmusicmanager.h.

◆ GetMIDIVolume()

void MxMusicManager::GetMIDIVolume ( DWORD & p_volume )

inline

Retrieves the current hardware MIDI out volume.

[AI]

If unable to get volume, sets to calculated value corresponding to 100%. [AI]

Parameters

p_volume Variable to receive current MIDI volume (hardware format, two-channel 0x0000HHHH | 0x0000LLLL). [AI]

Definition at line 61 of file mxmusicmanager.h.

◆ Init()

void MxMusicManager::Init ( )

protected

Initializes multipliers and buffer with default values; called from constructor/Destroy.

[AI]

Definition at line 24 of file mxmusicmanager.cpp.

◆ InitData()

void MxMusicManager::InitData ( )

protected

Initializes and zeros all associated MIDI-related member data.

[AI]

Used to reinitialize this object after deallocation or streaming end. [AI]

Definition at line 31 of file mxmusicmanager.cpp.

◆ InitializeMIDI()

MxResult MxMusicManager::InitializeMIDI	(	MxU8 *	p_data,
		MxS32	p_loopCount
	)

Initializes streaming for a MIDI data buffer and begins playback.

[AI]

Parameters

p_data	Pointer to MIDI data buffer, expected to be prepared for streaming. [AI]
p_loopCount	Number of times to loop playback, or -1 for infinite. [AI]

Returns: SUCCESS if initialization succeeds and playback starts, FAILURE otherwise. [AI]

Definition at line 208 of file mxmusicmanager.cpp.

◆ ResetBuffer()

void MxMusicManager::ResetBuffer ( )

Resets the MIDI buffer to the starting offset and sets the buffer size to the full stream.

[AI]

Definition at line 115 of file mxmusicmanager.cpp.

◆ ResetStream()

MxResult MxMusicManager::ResetStream ( )

Schedules and streams the next chunk of MIDI data; handles buffer looping and completion.

[AI]

Returns FAILURE on buffer underrun/error, or if looping/completion disables playback. [AI]

Definition at line 67 of file mxmusicmanager.cpp.

◆ SetMultiplier()

void MxMusicManager::SetMultiplier ( MxS32 p_multiplier )

Sets the volume multiplier for scaling volume output.

[AI]

Used for fade in/out or global gain controls on top of per-track volume. [AI]

Parameters

p_multiplier Multiplier value (percentage, where 100 = normal, 0 = muted). [AI]

Definition at line 192 of file mxmusicmanager.cpp.

◆ SetVolume()

void MxMusicManager::SetVolume ( MxS32 p_volume )

overridevirtual

Sets the music playback volume, taking into account multiplier for overall gain adjustment.

[AI]

Parameters

p_volume Percentage of the total volume (0-100). [AI]

Reimplemented from MxAudioManager.

Definition at line 183 of file mxmusicmanager.cpp.

The documentation for this class was generated from the following files:
