[AI] Central subsystem coordinator and singleton of the LEGO Island engine. More...

#include <mxomni.h>

Inheritance diagram for MxOmni:

Collaboration diagram for MxOmni:

[legend]

Public Member Functions
	MxOmni ()
	[AI] Initializes default state. More...

	~MxOmni () override
	[AI] Destroys all subsystems and releases memory/resources. More...

MxLong	Notify (MxParam &p_param) override
	[AI] Handles global notifications. More...

virtual void	Init ()
	[AI] Resets all internal pointers to defaults. More...

virtual MxResult	Create (MxOmniCreateParam &p_param)
	[AI] Allocates and configures engine subsystems, depending on the provided flags in MxOmniCreateParam. More...

virtual void	Destroy ()
	[AI] Tears down all engine subsystems, deletes and frees all managed memory. More...

virtual MxResult	Start (MxDSAction *p_dsAction)
	[AI] Requests the start of a top-level scripted action (from SI). More...

virtual void	DeleteObject (MxDSAction &p_dsAction)
	[AI] Deletes a world or subsystem object corresponding to an action. More...

virtual MxBool	DoesEntityExist (MxDSAction &p_dsAction)
	[AI] Checks whether an entity (gameplay object) exists by querying the streamer and notification manager. More...

virtual MxResult	CreatePresenter (MxStreamController *p_controller, MxDSAction &p_action)
	[AI] Instantiates and starts a Presenter (e.g., video, sound, animation) to handle the specified action on the given stream controller. More...

virtual MxEntity *	AddToWorld (const char , MxS32, MxPresenter )
	[AI] [VIRTUAL BASE] Placeholder virtual for derived engines to instantiate an entity and add to the 3D world. More...

virtual void	NotifyCurrentEntity (const MxNotificationParam &p_param)
	[AI] [VIRTUAL BASE] Placeholder for derived implementations—sends a notification to the currently active entity. More...

virtual void	Pause ()
	[AI] Pauses subsystems that support pausing (timer, sound manager) and sets paused state. More...

virtual void	Resume ()
	[AI] Resumes paused subsystems (timer, sound manager) and clears paused state. More...

virtual MxBool	IsPaused ()
	[AI] Returns paused state of the engine. More...

HWND	GetWindowHandle () const
	[AI] Gets the window handle (HWND) associated with the engine (ownership not transferred). More...

MxObjectFactory *	GetObjectFactory () const
	[AI] Retrieves the currently used object factory for presenter/entity instantiation (ownership not transferred). More...

MxNotificationManager *	GetNotificationManager () const
	[AI] Returns the notification manager responsible for enqueuing and dispatching notifications/events. More...

MxTickleManager *	GetTickleManager () const
	[AI] Returns the tickle manager which manages the tickle update loop for registered clients. More...

MxTimer *	GetTimer () const
	[AI] Gets the main frame-timer object (if any). More...

MxStreamer *	GetStreamer () const
	[AI] Returns the engine's global streamer object for media/data access. More...

MxSoundManager *	GetSoundManager () const
	[AI] Gets the engine's sound manager used for playing/controlling sounds. More...

MxVideoManager *	GetVideoManager () const
	[AI] Returns the video media manager (for handling FLC/SMK/etc.), if present. More...

MxVariableTable *	GetVariableTable () const
	[AI] Gets the global variable table for scripting/logic purposes. More...

MxMusicManager *	GetMusicManager () const
	[AI] Returns the current music manager, responsible for background/interactive music. More...

MxEventManager *	GetEventManager () const
	[AI] Get the event manager responsible for handling event queueing/dispatching. More...

MxAtomSet *	GetAtomSet () const
	[AI] Gets the atom set used for mapping strings/IDs to atom objects. More...

MxLong	HandleEndAction (MxParam &p_param)
	[AI] Handles the engine's response to action end notifications (c_notificationEndAction), deletes action objects as necessary and manages streamer state. More...

Public Member Functions inherited from MxCore
	MxCore ()
	[AI] Constructs a new MxCore object and assigns it a unique id. More...

virtual	~MxCore ()
	[AI] Virtual destructor. Required for correct polymorphic cleanup in derived classes. More...

virtual MxLong	Notify (MxParam &p_param)
	[AI] Virtual callback notification mechanism. More...

virtual MxResult	Tickle ()
	[AI] Called by tickle managers to allow the object to update itself. More...

virtual const char *	ClassName () const
	[AI] Returns the runtime class name of this object. More...

virtual MxBool	IsA (const char *p_name) const
	[AI] Checks whether this object's class type or parents match the given name. More...

MxU32	GetId ()
	[AI] Gets the unique (per-process) id assigned to this object instance. More...

Static Public Member Functions
static void	DestroyInstance ()
	[AI] Destroys the singleton MxOmni instance and performs memory cleanup. More...

static const char *	GetCD ()
	[AI] Retrieves the configured CD-ROM media path string used for resource location. More...

static const char *	GetHD ()
	[AI] Retrieves the configured hard disk media path string used for resource location. More...

static MxOmni *	GetInstance ()
	[AI] Returns the singleton instance of the MxOmni subsystem coordinator. More...

static MxBool	IsSound3D ()
	[AI] Returns current state of 3D sound configuration. More...

static void	SetCD (const char *p_cd)
	[AI] Sets the global CD media path used for source file lookup. More...

static void	SetHD (const char *p_hd)
	[AI] Sets the global hard disk media path used for resource lookup. More...

static void	SetSound3D (MxBool p_use3dSound)
	[AI] Enables or disables use of 3D sound processing. More...

static void	SetInstance (MxOmni *p_instance)
	[AI] Manually set the static instance of the global engine object. More...

static MxBool	ActionSourceEquals (MxDSAction p_action, const char p_name)
	[AI] Recursive walk to check if the given action, or any child multi-action, was sourced from the provided name. More...

Protected Attributes
MxString	m_mediaPath
	[AI] Path to media assets (SI files, resources) used for loading content. More...

HWND	m_windowHandle
	[AI] Associated window handle for DirectX/Win32 operations. More...

MxObjectFactory *	m_objectFactory
	[AI] Factory object used to instantiate engine objects (presenters, entities) by class name. More...

MxVariableTable *	m_variableTable
	[AI] Variable table for scripting/in-engine variable storage. More...

MxTickleManager *	m_tickleManager
	[AI] Manages list of objects requiring tickle updates each frame/step. More...

MxNotificationManager *	m_notificationManager
	[AI] Manages notifications and their distribution to interested clients. More...

MxVideoManager *	m_videoManager
	[AI] Manager for decoding and rendering video resources (FLC, etc.). More...

MxSoundManager *	m_soundManager
	[AI] Manages sound (WAV, MIDI) output and channels. More...

MxMusicManager *	m_musicManager
	[AI] Manages background and event-triggered music. More...

MxEventManager *	m_eventManager
	[AI] Centralized event manager for engine events (scripted/game logic). More...

MxTimer *	m_timer
	[AI] Master timer for time-keeping and scheduling. More...

MxStreamer *	m_streamer
	[AI] Main streamer for handling open files and distributed streaming. More...

MxAtomSet *	m_atomSet
	[AI] Global set of strings mapped to atom objects (for fast lookup/id assignment). More...

MxCriticalSection	m_criticalSection
	[AI] Critical section used for thread-safe engine operations. More...

MxBool	m_paused
	[AI] Indicates if the engine/systems are currently paused. More...

Static Protected Attributes
static MxOmni *	g_instance = NULL
	[AI] The singleton instance pointer of the MxOmni engine. More...

Detailed Description

[AI] Central subsystem coordinator and singleton of the LEGO Island engine.

Instantiated once in the process, this class manages all major subsystems such as resource streaming, variable tables, notification dispatch, media managers (sound/video/music), and event/timer systems. Also used for creation of subsystem objects and engine handling. Provides utility access to hardware paths and configuration (CD, HD, 3D sound).

[AI] Inherits from MxCore and is responsible for all high-level coordinated initialization, startup sequencing of media/actions, and teardown/cleanup of the game application. Patterned as an engine-wide singleton.

Definition at line 32 of file mxomni.h.

Constructor & Destructor Documentation

◆ MxOmni()

MxOmni::MxOmni ( )

[AI] Initializes default state.

Does not create or allocate any subsystems. [AI]

Definition at line 34 of file mxomni.cpp.

◆ ~MxOmni()

MxOmni::~MxOmni ( )

override

[AI] Destroys all subsystems and releases memory/resources.

[AI]

Definition at line 51 of file mxomni.cpp.

Member Function Documentation

◆ ActionSourceEquals()

MxBool MxOmni::ActionSourceEquals	(	MxDSAction *	p_action,
		const char *	p_name
	)

static

[AI] Recursive walk to check if the given action, or any child multi-action, was sourced from the provided name.

Parameters

p_action	The top-level or nested action to check (may be multi-action). [AI]
p_name	The name/string to compare as action source. [AI]

Returns: TRUE if found, FALSE otherwise. [AI]

Definition at line 304 of file mxomni.cpp.

◆ AddToWorld()

MxEntity * MxOmni::AddToWorld	(	const char *	,
		MxS32	,
		MxPresenter *
	)

virtual

[AI] [VIRTUAL BASE] Placeholder virtual for derived engines to instantiate an entity and add to the 3D world.

Not implemented in base class.

Parameters

[unused]	[description unavailable] [AI]
[unused]	[description unavailable] [AI]
[unused]	[description unavailable] [AI]

Returns: NULL by default. [AI]

Reimplemented in LegoOmni.

Definition at line 40 of file mxomni.cpp.

◆ Create()

MxResult MxOmni::Create ( MxOmniCreateParam & p_param )

virtual

[AI] Allocates and configures engine subsystems, depending on the provided flags in MxOmniCreateParam.

Handles creation of atom set, object factory, variable table, media managers, notification/event/timer/tickle/streamer subsystems as requested.

Parameters

p_param Configuration describing which subsystems to create. [AI]

Returns: SUCCESS if all requested subsystems are created and initialized, otherwise FAILURE. [AI]

Reimplemented in LegoOmni.

Definition at line 82 of file mxomni.cpp.

◆ CreatePresenter()

MxResult MxOmni::CreatePresenter	(	MxStreamController *	p_controller,
		MxDSAction &	p_action
	)

virtual

[AI] Instantiates and starts a Presenter (e.g., video, sound, animation) to handle the specified action on the given stream controller.

Name-dispatches to correct presenter type based on action format.

Parameters

p_controller	Stream controller managing the resource/media. [AI]
p_action	Action specifying presenter type and parameters. [AI]

Returns: SUCCESS if presenter was created, manager notification dispatched, and start succeeded. FAILURE otherwise. [AI]

Definition at line 245 of file mxomni.cpp.

◆ DeleteObject()

void MxOmni::DeleteObject ( MxDSAction & p_dsAction )

virtual

[AI] Deletes a world or subsystem object corresponding to an action.

Notifies streamer to unregister and clean up streaming resources associated with the action.

Parameters

p_dsAction The action whose resources/object should be deleted. [AI]

Reimplemented in LegoOmni.

Definition at line 237 of file mxomni.cpp.

◆ Destroy()

void MxOmni::Destroy ( )

virtual

[AI] Tears down all engine subsystems, deletes and frees all managed memory.

Also performs world object destruction. [AI]

Reimplemented in LegoOmni.

Definition at line 182 of file mxomni.cpp.

◆ DestroyInstance()

void MxOmni::DestroyInstance ( )

static

[AI] Destroys the singleton MxOmni instance and performs memory cleanup.

Should be called before application exit.

Definition at line 295 of file mxomni.cpp.

◆ DoesEntityExist()

MxBool MxOmni::DoesEntityExist ( MxDSAction & p_dsAction )

virtual

[AI] Checks whether an entity (gameplay object) exists by querying the streamer and notification manager.

Parameters

p_dsAction The action referencing the entity (usually by ID or AtomID). [AI]

Returns: TRUE if entity exists and no queued notifications for deletion remain, FALSE otherwise. [AI]

Reimplemented in LegoOmni.

Definition at line 399 of file mxomni.cpp.

◆ GetAtomSet()

MxAtomSet * MxOmni::GetAtomSet ( ) const

inline

[AI] Gets the atom set used for mapping strings/IDs to atom objects.

Returns: Pointer to the atom set. [AI]

Definition at line 258 of file mxomni.h.

◆ GetCD()

const char * MxOmni::GetCD ( )

static

[AI] Retrieves the configured CD-ROM media path string used for resource location.

Returns: Pointer to a string containing the path to CD media. [AI]

Definition at line 375 of file mxomni.cpp.

◆ GetEventManager()

MxEventManager * MxOmni::GetEventManager ( ) const

inline

[AI] Get the event manager responsible for handling event queueing/dispatching.

Returns: Pointer to event manager. [AI]

Definition at line 252 of file mxomni.h.

◆ GetHD()

const char * MxOmni::GetHD ( )

static

[AI] Retrieves the configured hard disk media path string used for resource location.

Returns: Pointer to a string containing the path to the HD media. [AI]

Definition at line 363 of file mxomni.cpp.

◆ GetInstance()

MxOmni * MxOmni::GetInstance ( )

static

[AI] Returns the singleton instance of the MxOmni subsystem coordinator.

Returns: Pointer to the global engine singleton. [AI]

Definition at line 289 of file mxomni.cpp.

◆ GetMusicManager()

MxMusicManager * MxOmni::GetMusicManager ( ) const

inline

[AI] Returns the current music manager, responsible for background/interactive music.

Returns: Pointer to music manager. [AI]

Definition at line 246 of file mxomni.h.

◆ GetNotificationManager()

MxNotificationManager * MxOmni::GetNotificationManager ( ) const

inline

[AI] Returns the notification manager responsible for enqueuing and dispatching notifications/events.

Returns: Notification manager. [AI]

Definition at line 204 of file mxomni.h.

◆ GetObjectFactory()

MxObjectFactory * MxOmni::GetObjectFactory ( ) const

inline

[AI] Retrieves the currently used object factory for presenter/entity instantiation (ownership not transferred).

Returns: Pointer to global object factory. [AI]

Definition at line 198 of file mxomni.h.

◆ GetSoundManager()

MxSoundManager * MxOmni::GetSoundManager ( ) const

inline

[AI] Gets the engine's sound manager used for playing/controlling sounds.

Returns: Sound manager object. [AI]

Definition at line 228 of file mxomni.h.

◆ GetStreamer()

MxStreamer * MxOmni::GetStreamer ( ) const

inline

[AI] Returns the engine's global streamer object for media/data access.

Returns: Pointer to streamer subsystem. [AI]

Definition at line 222 of file mxomni.h.

◆ GetTickleManager()

MxTickleManager * MxOmni::GetTickleManager ( ) const

inline

[AI] Returns the tickle manager which manages the tickle update loop for registered clients.

Returns: Pointer to tickle manager. [AI]

Definition at line 210 of file mxomni.h.

◆ GetTimer()

MxTimer * MxOmni::GetTimer ( ) const

inline

[AI] Gets the main frame-timer object (if any).

Returns: Pointer to engine timer. [AI]

Definition at line 216 of file mxomni.h.

◆ GetVariableTable()

MxVariableTable * MxOmni::GetVariableTable ( ) const

inline

[AI] Gets the global variable table for scripting/logic purposes.

Returns: The variable table used for storing game variables/values. [AI]

Definition at line 240 of file mxomni.h.

◆ GetVideoManager()

MxVideoManager * MxOmni::GetVideoManager ( ) const

inline

[AI] Returns the video media manager (for handling FLC/SMK/etc.), if present.

Returns: Video manager instance. [AI]

Definition at line 234 of file mxomni.h.

◆ GetWindowHandle()

HWND MxOmni::GetWindowHandle ( ) const

inline

[AI] Gets the window handle (HWND) associated with the engine (ownership not transferred).

Returns: Window handle. [AI]

Definition at line 192 of file mxomni.h.

◆ HandleEndAction()

MxLong MxOmni::HandleEndAction ( MxParam & p_param )

[AI] Handles the engine's response to action end notifications (c_notificationEndAction), deletes action objects as necessary and manages streamer state.

Parameters

p_param End action notification parameter. [AI]

Returns: Always 1 to acknowledge handling. [AI]

Definition at line 337 of file mxomni.cpp.

◆ Init()

void MxOmni::Init ( )

virtual

[AI] Resets all internal pointers to defaults.

Subsystem pointers are set to NULL. Window handle and paused state reset.

Reimplemented in LegoOmni.

Definition at line 57 of file mxomni.cpp.

◆ IsPaused()

virtual MxBool MxOmni::IsPaused ( )

inlinevirtual

[AI] Returns paused state of the engine.

[AI]

Returns: True if the engine is currently paused, false otherwise. [AI]

Definition at line 172 of file mxomni.h.

◆ IsSound3D()

MxBool MxOmni::IsSound3D ( )

static

[AI] Returns current state of 3D sound configuration.

Returns: TRUE if 3D sound output should be used; FALSE otherwise. [AI]

Definition at line 387 of file mxomni.cpp.

◆ Notify()

MxLong MxOmni::Notify ( MxParam & p_param )

overridevirtual

[AI] Handles global notifications.

Handles c_notificationEndAction and delegates to HandleEndAction.

Parameters

p_param Incoming notification/parameter. [AI]

Returns: 1 if handled (end action), else 0. [AI]

Reimplemented from MxCore.

Definition at line 325 of file mxomni.cpp.

◆ NotifyCurrentEntity()

void MxOmni::NotifyCurrentEntity ( const MxNotificationParam & p_param )

virtual

[AI] [VIRTUAL BASE] Placeholder for derived implementations—sends a notification to the currently active entity.

Not implemented in base. [AI]

Parameters

p_param Notification parameters to send. [AI]

Reimplemented in LegoOmni.

Definition at line 46 of file mxomni.cpp.

◆ Pause()

void MxOmni::Pause ( )

virtual

[AI] Pauses subsystems that support pausing (timer, sound manager) and sets paused state.

Reimplemented in LegoOmni.

Definition at line 412 of file mxomni.cpp.

◆ Resume()

void MxOmni::Resume ( )

virtual

[AI] Resumes paused subsystems (timer, sound manager) and clears paused state.

Reimplemented in LegoOmni.

Definition at line 422 of file mxomni.cpp.

◆ SetCD()

void MxOmni::SetCD ( const char * p_cd )

static

[AI] Sets the global CD media path used for source file lookup.

Parameters

p_cd	The new CD path to use for resource access. [AI]

Definition at line 381 of file mxomni.cpp.

◆ SetHD()

void MxOmni::SetHD ( const char * p_hd )

static

[AI] Sets the global hard disk media path used for resource lookup.

Parameters

p_hd	The new HD path to use for resource access. [AI]

Definition at line 369 of file mxomni.cpp.

◆ SetInstance()

void MxOmni::SetInstance ( MxOmni * p_instance )

static

[AI] Manually set the static instance of the global engine object.

Parameters

p_instance The new instance pointer. [AI]

Definition at line 75 of file mxomni.cpp.

◆ SetSound3D()

void MxOmni::SetSound3D ( MxBool p_use3dSound )

static

[AI] Enables or disables use of 3D sound processing.

Parameters

p_use3dSound Set TRUE to enable 3D sound, FALSE otherwise. [AI]

Definition at line 393 of file mxomni.cpp.

◆ Start()

MxResult MxOmni::Start ( MxDSAction * p_dsAction )

virtual

[AI] Requests the start of a top-level scripted action (from SI).

Triggers sequence execution for streaming/media/subsystems as required by the action, via streamer.

Parameters

p_dsAction The action object (parsed from SI) to be started. [AI]

Returns: SUCCESS if streaming was successfully initiated, FAILURE if requirements not met or error occurred. [AI]

[AI] Associated window handle for DirectX/Win32 operations.

[AI]

Definition at line 284 of file mxomni.h.

The documentation for this class was generated from the following files:

Public Member Functions

Static Public Member Functions

Protected Attributes

Static Protected Attributes

Detailed Description

Constructor & Destructor Documentation

◆ MxOmni()

◆ ~MxOmni()

Member Function Documentation

◆ ActionSourceEquals()

◆ AddToWorld()

◆ Create()

◆ CreatePresenter()

◆ DeleteObject()

◆ Destroy()

◆ DestroyInstance()

◆ DoesEntityExist()

◆ GetAtomSet()

◆ GetCD()

◆ GetEventManager()

◆ GetHD()

◆ GetInstance()

◆ GetMusicManager()

◆ GetNotificationManager()

◆ GetObjectFactory()

◆ GetSoundManager()

◆ GetStreamer()

◆ GetTickleManager()

◆ GetTimer()

◆ GetVariableTable()

◆ GetVideoManager()

◆ GetWindowHandle()

◆ HandleEndAction()

◆ Init()

◆ IsPaused()

◆ IsSound3D()

◆ Notify()

◆ NotifyCurrentEntity()

◆ Pause()

◆ Resume()

◆ SetCD()

◆ SetHD()

◆ SetInstance()

◆ SetSound3D()

◆ Start()

Member Data Documentation

◆ g_instance

◆ m_atomSet

◆ m_criticalSection

◆ m_eventManager

◆ m_mediaPath

◆ m_musicManager

◆ m_notificationManager

◆ m_objectFactory

◆ m_paused

◆ m_soundManager

◆ m_streamer

◆ m_tickleManager

◆ m_timer

◆ m_variableTable

◆ m_videoManager

◆ m_windowHandle
