[AI] Central hub singleton for the LEGO Island game engine, managing all core game systems, state, world switching, and providing high-level access to all major engine subsystems. More...

#include <legomain.h>

Inheritance diagram for LegoOmni:

[legend]

Collaboration diagram for LegoOmni:

[legend]

Classes
struct	WorldContainer
	[AI] Associates a world enum, key, and AtomId for dynamic world lookup, Atom-based registry, and key-string identification. More...

Public Types
enum	{ c_disableInput = 0x01 , c_disable3d = 0x02 , c_clearScreen = 0x04 }

enum	World { e_undefined = -1 , e_act1 = 0 , e_imain , e_icube , e_ireg , e_ielev , e_iisle , e_hosp , e_police , e_gmain , e_bldh , e_bldd , e_bldj , e_bldr , e_racc , e_racj , e_act2 , e_act3 , e_test , e_numWorlds = e_test + 2 }
	[AI] Identifiers for all unique, script-driven world environments in LEGO Island. More...

Public Member Functions
	LegoOmni ()
	[AI] Constructs the LegoOmni singleton and initializes all internal pointers to NULL/default state. More...

	~LegoOmni () override
	[AI] Tears down LegoOmni, deleting or unregistering all major owned game systems and registry lists. More...

MxLong	Notify (MxParam &p_param) override
	[AI] Handles notification messages sent to the engine, including EndAction notifications for quitting, etc. More...

const char *	ClassName () const override
	[AI] Returns a static string identifying this class for runtime type checking. More...

MxBool	IsA (const char *p_name) const override
	[AI] Performs runtime type checking, supporting inheritance. More...

void	Init () override
	[AI] Performs LegoOmni member and subsystem initialization. More...

MxResult	Create (MxOmniCreateParam &p_param) override
	[AI] Creates and initializes all subsystems for the game, wiring up all managers and attaching Lego-specific logic. More...

void	Destroy () override
	[AI] Shuts down and deletes all owned game managers, variable tables, registry lists and Lego subsystems. More...

MxResult	Start (MxDSAction *p_dsAction) override
	[AI] Begins executing the specified DSAction/script in the context of the current world/state. More...

void	DeleteObject (MxDSAction &p_dsAction) override
	[AI] Deletes an entity or world referenced by the given DSAction (by object and Atom), cascading to removal in current world. More...

MxBool	DoesEntityExist (MxDSAction &p_dsAction) override
	[AI] Checks if the entity described by the DSAction does NOT exist in worlds (true if not found, false if found). More...

MxEntity *	AddToWorld (const char p_id, MxS32 p_entityId, MxPresenter p_presenter) override
	[AI] Adds an entity presenter to the specified world (by id or current). More...

void	NotifyCurrentEntity (const MxNotificationParam &p_param) override
	[AI] Sends notification to the currently active world. More...

void	Pause () override
	[AI] Pauses the engine/game state and sets busy cursor. More...

void	Resume () override
	[AI] Resumes engine/game state and sets default cursor. More...

LegoWorld *	FindWorld (const MxAtomId &p_atom, MxS32 p_entityid)
	[AI] Finds and returns the LegoWorld by AtomId and/or entity id. More...

LegoROI *	FindROI (const char *p_name)
	[AI] Finds a top-level LegoROI (region of interest/3D object) by name string. More...

void	AddWorld (LegoWorld *p_world)
	[AI] Appends a LegoWorld to the active world list, acquiring ownership. More...

void	DeleteWorld (LegoWorld *p_world)
	[AI] Deletes (and removes from registry) a LegoWorld, deleting all resources. More...

void	FUN_1005b4f0 (MxBool p_disable, MxU16 p_flags)
	[AI] Enables or disables input/3d/screen clearing in a single call, based on flags. More...

void	CreateBackgroundAudio ()
	[AI] Initializes background audio manager and starts music using global script. More...

void	RemoveWorld (const MxAtomId &p_atom, MxLong p_objectId)
	[AI] Removes worlds by Atom and/or id, deleting matching entries from the world list and freeing resources. More...

MxResult	RegisterWorlds ()
	[AI] Registers all builtin worlds/scripts into the world's Atom/registry list (m_worlds). More...

const char *	GetWorldName (LegoOmni::World p_id)
	[AI] Looks up and returns the registered world key for a world id. More...

MxAtomId *	GetWorldAtom (LegoOmni::World p_id)
	[AI] Looks up and returns the AtomId of a world by its enum id. More...

World	GetWorldId (const char *p_key)
	[AI] Looks up a World enum id from its string key. More...

void	DeleteAction ()
	[AI] Deletes and clears the current DSAction used for world/entity tracking. More...

LegoVideoManager *	GetVideoManager ()
	[AI] Returns the active video manager, cast to LegoVideoManager. More...

LegoSoundManager *	GetSoundManager ()
	[AI] Returns the sound manager, cast to LegoSoundManager. More...

LegoInputManager *	GetInputManager ()
	[AI] Returns the input manager. More...

LegoTextureContainer *	GetTextureContainer ()
	[AI] Returns the global texture container (all loaded textures). More...

ViewLODListManager *	GetViewLODListManager ()
	[AI] Returns the LOD list manager for handling refcounted LOD data in the scene. More...

LegoWorld *	GetCurrentWorld ()
	[AI] Returns the pointer to the currently active world. More...

LegoNavController *	GetNavController ()
	[AI] Returns the navigation controller (handles player navigation and camera logic). More...

LegoPathActor *	GetUserActor ()
	[AI] Returns the player-controlled ("user") actor. More...

LegoPlantManager *	GetPlantManager ()
	[AI] Returns active plant manager, which tracks in-world plants/objects. More...

LegoAnimationManager *	GetAnimationManager ()
	[AI] Returns animation manager for managing character/world animations. More...

LegoBuildingManager *	GetBuildingManager ()
	[AI] Returns building manager (handles in-world structures and their logic). More...

LegoWorldList *	GetWorldList ()
	[AI] Returns pointer to world and script registry list. More...

LegoGameState *	GetGameState ()
	[AI] Returns the global game state tracker. More...

MxBackgroundAudioManager *	GetBackgroundAudioManager ()
	[AI] Returns handle to the background audio manager (jukebox/music/ambience). More...

MxTransitionManager *	GetTransitionManager ()
	[AI] Returns transition manager for handling UI/game state transitions/fades. More...

MxDSAction &	GetCurrentAction ()
	[AI] Returns the actual DSAction used for the current/pending event. More...

LegoCharacterManager *	GetCharacterManager ()
	[AI] Returns character manager, handling population and logic for all in-world characters. More...

void	SetNavController (LegoNavController *p_navController)
	[AI] Sets the navigation controller. More...

void	SetUserActor (LegoPathActor *p_userActor)
	[AI] Sets the user actor pointer (player). More...

void	SetCurrentWorld (LegoWorld *p_currentWorld)
	[AI] Sets the current world pointer for global context. More...

void	SetExit (MxBool p_exit)
	[AI] Signals the engine to exit/game quit procedure. More...

MxResult	StartActionIfUnknown0x13c (MxDSAction &p_dsAction)
	[AI] Starts action if the unknown0x13c member is set; otherwise returns success. More...

void	SetUnknown13c (MxBool p_unk0x13c)
	[AI] Sets the unknown0x13c flag (purpose not fully documented in reverse). More...

void	CloseMainWindow ()
	[AI] Posts a close (exit) message to the main window handle, triggering shutdown. More...

Public Member Functions inherited from MxOmni
	MxOmni ()
	[AI] Initializes default state. More...

	~MxOmni () override
	[AI] Destroys all subsystems and releases memory/resources. More...

MxLong	Notify (MxParam &p_param) override
	[AI] Handles global notifications. More...

virtual void	Init ()
	[AI] Resets all internal pointers to defaults. More...

virtual MxResult	Create (MxOmniCreateParam &p_param)
	[AI] Allocates and configures engine subsystems, depending on the provided flags in MxOmniCreateParam. More...

virtual void	Destroy ()
	[AI] Tears down all engine subsystems, deletes and frees all managed memory. More...

virtual MxResult	Start (MxDSAction *p_dsAction)
	[AI] Requests the start of a top-level scripted action (from SI). More...

virtual void	DeleteObject (MxDSAction &p_dsAction)
	[AI] Deletes a world or subsystem object corresponding to an action. More...

virtual MxBool	DoesEntityExist (MxDSAction &p_dsAction)
	[AI] Checks whether an entity (gameplay object) exists by querying the streamer and notification manager. More...

virtual MxResult	CreatePresenter (MxStreamController *p_controller, MxDSAction &p_action)
	[AI] Instantiates and starts a Presenter (e.g., video, sound, animation) to handle the specified action on the given stream controller. More...

virtual MxEntity *	AddToWorld (const char , MxS32, MxPresenter )
	[AI] [VIRTUAL BASE] Placeholder virtual for derived engines to instantiate an entity and add to the 3D world. More...

virtual void	NotifyCurrentEntity (const MxNotificationParam &p_param)
	[AI] [VIRTUAL BASE] Placeholder for derived implementations—sends a notification to the currently active entity. More...

virtual void	Pause ()
	[AI] Pauses subsystems that support pausing (timer, sound manager) and sets paused state. More...

virtual void	Resume ()
	[AI] Resumes paused subsystems (timer, sound manager) and clears paused state. More...

virtual MxBool	IsPaused ()
	[AI] Returns paused state of the engine. More...

HWND	GetWindowHandle () const
	[AI] Gets the window handle (HWND) associated with the engine (ownership not transferred). More...

MxObjectFactory *	GetObjectFactory () const
	[AI] Retrieves the currently used object factory for presenter/entity instantiation (ownership not transferred). More...

MxNotificationManager *	GetNotificationManager () const
	[AI] Returns the notification manager responsible for enqueuing and dispatching notifications/events. More...

MxTickleManager *	GetTickleManager () const
	[AI] Returns the tickle manager which manages the tickle update loop for registered clients. More...

MxTimer *	GetTimer () const
	[AI] Gets the main frame-timer object (if any). More...

MxStreamer *	GetStreamer () const
	[AI] Returns the engine's global streamer object for media/data access. More...

MxSoundManager *	GetSoundManager () const
	[AI] Gets the engine's sound manager used for playing/controlling sounds. More...

MxVideoManager *	GetVideoManager () const
	[AI] Returns the video media manager (for handling FLC/SMK/etc.), if present. More...

MxVariableTable *	GetVariableTable () const
	[AI] Gets the global variable table for scripting/logic purposes. More...

MxMusicManager *	GetMusicManager () const
	[AI] Returns the current music manager, responsible for background/interactive music. More...

MxEventManager *	GetEventManager () const
	[AI] Get the event manager responsible for handling event queueing/dispatching. More...

MxAtomSet *	GetAtomSet () const
	[AI] Gets the atom set used for mapping strings/IDs to atom objects. More...

MxLong	HandleEndAction (MxParam &p_param)
	[AI] Handles the engine's response to action end notifications (c_notificationEndAction), deletes action objects as necessary and manages streamer state. More...

Public Member Functions inherited from MxCore
	MxCore ()
	[AI] Constructs a new MxCore object and assigns it a unique id. More...

virtual	~MxCore ()
	[AI] Virtual destructor. Required for correct polymorphic cleanup in derived classes. More...

virtual MxLong	Notify (MxParam &p_param)
	[AI] Virtual callback notification mechanism. More...

virtual MxResult	Tickle ()
	[AI] Called by tickle managers to allow the object to update itself. More...

virtual const char *	ClassName () const
	[AI] Returns the runtime class name of this object. More...

virtual MxBool	IsA (const char *p_name) const
	[AI] Checks whether this object's class type or parents match the given name. More...

MxU32	GetId ()
	[AI] Gets the unique (per-process) id assigned to this object instance. More...

Static Public Member Functions
static MxS32	GetCurrPathInfo (LegoPathBoundary **, MxS32 &)
	[AI] Static utility for retrieving current path boundary and info from the current world. More...

static void	CreateInstance ()
	[AI] Allocates and sets up a new LegoOmni singleton instance, replacing the previous one if any. More...

static LegoOmni *	GetInstance ()
	[AI] Returns the current LegoOmni singleton pointer, cast from MxOmni. More...

Static Public Member Functions inherited from MxOmni
static void	DestroyInstance ()
	[AI] Destroys the singleton MxOmni instance and performs memory cleanup. More...

static const char *	GetCD ()
	[AI] Retrieves the configured CD-ROM media path string used for resource location. More...

static const char *	GetHD ()
	[AI] Retrieves the configured hard disk media path string used for resource location. More...

static MxOmni *	GetInstance ()
	[AI] Returns the singleton instance of the MxOmni subsystem coordinator. More...

static MxBool	IsSound3D ()
	[AI] Returns current state of 3D sound configuration. More...

static void	SetCD (const char *p_cd)
	[AI] Sets the global CD media path used for source file lookup. More...

static void	SetHD (const char *p_hd)
	[AI] Sets the global hard disk media path used for resource lookup. More...

static void	SetSound3D (MxBool p_use3dSound)
	[AI] Enables or disables use of 3D sound processing. More...

static void	SetInstance (MxOmni *p_instance)
	[AI] Manually set the static instance of the global engine object. More...

static MxBool	ActionSourceEquals (MxDSAction p_action, const char p_name)
	[AI] Recursive walk to check if the given action, or any child multi-action, was sourced from the provided name. More...

Public Attributes
MxBool	m_unk0x13c
	[AI] Unknown flag used in rare start-action cases. [AI] More...

Additional Inherited Members
Protected Attributes inherited from MxOmni
MxString	m_mediaPath
	[AI] Path to media assets (SI files, resources) used for loading content. More...

HWND	m_windowHandle
	[AI] Associated window handle for DirectX/Win32 operations. More...

MxObjectFactory *	m_objectFactory
	[AI] Factory object used to instantiate engine objects (presenters, entities) by class name. More...

MxVariableTable *	m_variableTable
	[AI] Variable table for scripting/in-engine variable storage. More...

MxTickleManager *	m_tickleManager
	[AI] Manages list of objects requiring tickle updates each frame/step. More...

MxNotificationManager *	m_notificationManager
	[AI] Manages notifications and their distribution to interested clients. More...

MxVideoManager *	m_videoManager
	[AI] Manager for decoding and rendering video resources (FLC, etc.). More...

MxSoundManager *	m_soundManager
	[AI] Manages sound (WAV, MIDI) output and channels. More...

MxMusicManager *	m_musicManager
	[AI] Manages background and event-triggered music. More...

MxEventManager *	m_eventManager
	[AI] Centralized event manager for engine events (scripted/game logic). More...

MxTimer *	m_timer
	[AI] Master timer for time-keeping and scheduling. More...

MxStreamer *	m_streamer
	[AI] Main streamer for handling open files and distributed streaming. More...

MxAtomSet *	m_atomSet
	[AI] Global set of strings mapped to atom objects (for fast lookup/id assignment). More...

MxCriticalSection	m_criticalSection
	[AI] Critical section used for thread-safe engine operations. More...

MxBool	m_paused
	[AI] Indicates if the engine/systems are currently paused. More...

Static Protected Attributes inherited from MxOmni
static MxOmni *	g_instance = NULL
	[AI] The singleton instance pointer of the MxOmni engine. More...

Detailed Description

[AI] Central hub singleton for the LEGO Island game engine, managing all core game systems, state, world switching, and providing high-level access to all major engine subsystems.

[AI] Engine singleton managing LEGO Island's subsystems and game state.

Handles initialization, teardown, world registry, notification dispatching, and singleton instance management.

[AI] LegoOmni extends MxOmni to provide high-level game coordination, resource and manager ownership, dynamic world and entity management, script/action handling, background audio, global state, and event notification. It encapsulates systems for animation, input, world/ROI lookup, tickling, building/plants, and more. The class also provides interface entry points for interacting with video, audio, presenter logic, and game state—making it effectively the "heart" of the LEGO Island runtime architecture.

[AI]

Definition at line 40 of file legomain.h.

Member Enumeration Documentation

◆ anonymous enum

anonymous enum

Enumerator
c_disableInput	[AI] When set, disables input processing. [AI]
c_disable3d	[AI] When set, disables 3D rendering. [AI]
c_clearScreen	[AI] When set, clears the display surface. [AI]

Definition at line 46 of file legomain.h.

◆ World

enum LegoOmni::World

[AI] Identifiers for all unique, script-driven world environments in LEGO Island.

Used for dynamic lookup, registry, and scheduling. [AI]

[AI] Each enum value corresponds to a logical world space, typically associated with a key, script, and AtomId. e_numWorlds is the total. [AI]

Enumerator
e_undefined	[AI] No world specified. [AI]
e_act1	[AI] Act 1 main world. [AI]
e_imain	[AI] Information main building. [AI]
e_icube	[AI] Information cube building. [AI]
e_ireg	[AI] Information registration/building. [AI]
e_ielev	[AI] Information elevator. [AI]
e_iisle	[AI] Information Isle room. [AI]
e_hosp	[AI] Hospital. [AI]
e_police	[AI] Police station. [AI]
e_gmain	[AI] Garage. [AI]
e_bldh	[AI] Helicopter building. [AI]
e_bldd	[AI] Dune car building. [AI]
e_bldj	[AI] Jet ski building. [AI]
e_bldr	[AI] Race car building. [AI]
e_racc	[AI] Car race area/world. [AI]
e_racj	[AI] Jet race area/world. [AI]
e_act2	[AI] Act 2. [AI]
e_act3	[AI] Act 3. [AI]
e_test	[AI] Test world. [AI]
e_numWorlds	[AI] Number of worlds (includes undefined, test, or unused). [AI]

Definition at line 57 of file legomain.h.

Constructor & Destructor Documentation

◆ LegoOmni()

LegoOmni::LegoOmni ( )

[AI] Constructs the LegoOmni singleton and initializes all internal pointers to NULL/default state.

Begins game system setup.

Definition at line 45 of file legomain.cpp.

◆ ~LegoOmni()

LegoOmni::~LegoOmni ( )

override

[AI] Tears down LegoOmni, deleting or unregistering all major owned game systems and registry lists.

Definition at line 51 of file legomain.cpp.

Member Function Documentation

◆ AddToWorld()

MxEntity * LegoOmni::AddToWorld	(	const char *	p_id,
		MxS32	p_entityId,
		MxPresenter *	p_presenter
	)

overridevirtual

[AI] Adds an entity presenter to the specified world (by id or current).

Intended for dynamic entity loading.

Parameters

p_id	[AI] World id string or "current".
p_entityId	[AI] Entity id number for lookup.
p_presenter	[AI] Presenter object to attach (e.g. for video, sound, model).

Returns: [AI] Pointer to the LegoWorld the presenter was added to, or NULL if not found.

Reimplemented from MxOmni.

Definition at line 430 of file legomain.cpp.

◆ AddWorld()

void LegoOmni::AddWorld ( LegoWorld * p_world )

[AI] Appends a LegoWorld to the active world list, acquiring ownership.

Parameters

p_world [AI] The LegoWorld to add.

Definition at line 311 of file legomain.cpp.

◆ ClassName()

const char * LegoOmni::ClassName ( ) const

inlineoverridevirtual

[AI] Returns a static string identifying this class for runtime type checking.

Returns: [AI] String "LegoOmni".

Reimplemented from MxCore.

Definition at line 163 of file legomain.h.

◆ CloseMainWindow()

void LegoOmni::CloseMainWindow ( )

inline

[AI] Posts a close (exit) message to the main window handle, triggering shutdown.

Definition at line 479 of file legomain.h.

◆ Create()

MxResult LegoOmni::Create ( MxOmniCreateParam & p_param )

overridevirtual

[AI] Creates and initializes all subsystems for the game, wiring up all managers and attaching Lego-specific logic.

Parameters

p_param [AI] Creation parameter block with flags and resource hints.

Returns: [AI] Result code: SUCCESS, or FAILURE if allocation/creation fails.

Reimplemented from MxOmni.

Definition at line 156 of file legomain.cpp.

◆ CreateBackgroundAudio()

void LegoOmni::CreateBackgroundAudio ( )

[AI] Initializes background audio manager and starts music using global script.

Definition at line 540 of file legomain.cpp.

◆ CreateInstance()

void LegoOmni::CreateInstance ( )

static

[AI] Allocates and sets up a new LegoOmni singleton instance, replacing the previous one if any.

Definition at line 298 of file legomain.cpp.

◆ DeleteAction()

void LegoOmni::DeleteAction ( )

[AI] Deletes and clears the current DSAction used for world/entity tracking.

Definition at line 558 of file legomain.cpp.

◆ DeleteObject()

void LegoOmni::DeleteObject ( MxDSAction & p_dsAction )

overridevirtual

[AI] Deletes an entity or world referenced by the given DSAction (by object and Atom), cascading to removal in current world.

Parameters

p_dsAction [AI] DSAction describing which entity/world to delete.

Reimplemented from MxOmni.

Definition at line 378 of file legomain.cpp.

◆ DeleteWorld()

void LegoOmni::DeleteWorld ( LegoWorld * p_world )

[AI] Deletes (and removes from registry) a LegoWorld, deleting all resources.

Parameters

p_world [AI] The world to be deleted.

Definition at line 317 of file legomain.cpp.

◆ Destroy()

void LegoOmni::Destroy ( )

overridevirtual

[AI] Shuts down and deletes all owned game managers, variable tables, registry lists and Lego subsystems.

Reimplemented from MxOmni.

Definition at line 79 of file legomain.cpp.

◆ DoesEntityExist()

MxBool LegoOmni::DoesEntityExist ( MxDSAction & p_dsAction )

overridevirtual

[AI] Checks if the entity described by the DSAction does NOT exist in worlds (true if not found, false if found).

Parameters

p_dsAction [AI] DSAction describing entity.

Returns: [AI] TRUE if entity does not exist/was removed, FALSE if still present.

Reimplemented from MxOmni.

Definition at line 457 of file legomain.cpp.

◆ FindROI()

LegoROI * LegoOmni::FindROI ( const char * p_name )

[AI] Finds a top-level LegoROI (region of interest/3D object) by name string.

Parameters

p_name [AI] Name of the ROI.

Returns: [AI] Pointer to LegoROI if found, else NULL.

Definition at line 408 of file legomain.cpp.

◆ FindWorld()

LegoWorld * LegoOmni::FindWorld	(	const MxAtomId &	p_atom,
		MxS32	p_entityid
	)

[AI] Finds and returns the LegoWorld by AtomId and/or entity id.

Parameters

p_atom	[AI] AtomId for the world.
p_entityid	[AI] Entity id (or -1 to skip id check).

Returns: [AI] Pointer to LegoWorld if found, else NULL.

Definition at line 360 of file legomain.cpp.

◆ FUN_1005b4f0()

void LegoOmni::FUN_1005b4f0	(	MxBool	p_disable,
		MxU16	p_flags
	)

[AI] Enables or disables input/3d/screen clearing in a single call, based on flags.

Used for game-wide state gating.

Parameters

p_disable	[AI] TRUE disables (according to flags); FALSE enables.
p_flags	[AI] Bit field of c_disableInput, c_disable3d, c_clearScreen.

Definition at line 517 of file legomain.cpp.

◆ GetAnimationManager()

LegoAnimationManager * LegoOmni::GetAnimationManager ( )

inline

[AI] Returns animation manager for managing character/world animations.

Returns: [AI] Animation manager pointer.

Definition at line 395 of file legomain.h.

◆ GetBackgroundAudioManager()

MxBackgroundAudioManager * LegoOmni::GetBackgroundAudioManager ( )

inline

[AI] Returns handle to the background audio manager (jukebox/music/ambience).

Returns: [AI] Background audio manager pointer.

Definition at line 419 of file legomain.h.

◆ GetBuildingManager()

LegoBuildingManager * LegoOmni::GetBuildingManager ( )

inline

[AI] Returns building manager (handles in-world structures and their logic).

Returns: [AI] Building manager pointer.

Definition at line 401 of file legomain.h.

◆ GetCharacterManager()

LegoCharacterManager * LegoOmni::GetCharacterManager ( )

inline

[AI] Returns character manager, handling population and logic for all in-world characters.

Returns: [AI] Character manager pointer.

Definition at line 437 of file legomain.h.

◆ GetCurrentAction()

MxDSAction & LegoOmni::GetCurrentAction ( )

inline

[AI] Returns the actual DSAction used for the current/pending event.

Returns: [AI] Current action reference.

Definition at line 431 of file legomain.h.

◆ GetCurrentWorld()

LegoWorld * LegoOmni::GetCurrentWorld ( )

inline

[AI] Returns the pointer to the currently active world.

Returns: [AI] The current LegoWorld instance.

Definition at line 371 of file legomain.h.

◆ GetCurrPathInfo()

MxS32 LegoOmni::GetCurrPathInfo	(	LegoPathBoundary **	p_path,
		MxS32 &	p_value
	)

static

[AI] Static utility for retrieving current path boundary and info from the current world.

Parameters

p_path	[AI] Output: pointer to path boundary.
p_value	[AI] Output: integer info.

Returns: [AI] FAILURE if no world, else world-specific result.

Definition at line 468 of file legomain.cpp.

◆ GetGameState()

LegoGameState * LegoOmni::GetGameState ( )

inline

[AI] Returns the global game state tracker.

Returns: [AI] Game state pointer.

Definition at line 413 of file legomain.h.

◆ GetInputManager()

LegoInputManager * LegoOmni::GetInputManager ( )

inline

[AI] Returns the input manager.

Returns: [AI] Input manager.

Definition at line 353 of file legomain.h.

◆ GetInstance()

LegoOmni * LegoOmni::GetInstance ( )

static

[AI] Returns the current LegoOmni singleton pointer, cast from MxOmni.

Returns: [AI] Singleton pointer.

Definition at line 305 of file legomain.cpp.

◆ GetNavController()

LegoNavController * LegoOmni::GetNavController ( )

inline

[AI] Returns the navigation controller (handles player navigation and camera logic).

Returns: [AI] Nav controller pointer.

Definition at line 377 of file legomain.h.

◆ GetPlantManager()

LegoPlantManager * LegoOmni::GetPlantManager ( )

inline

[AI] Returns active plant manager, which tracks in-world plants/objects.

Returns: [AI] Plant manager pointer.

Definition at line 389 of file legomain.h.

◆ GetSoundManager()

LegoSoundManager * LegoOmni::GetSoundManager ( )

inline

[AI] Returns the sound manager, cast to LegoSoundManager.

Returns: [AI] Sound manager instance.

Definition at line 347 of file legomain.h.

◆ GetTextureContainer()

LegoTextureContainer * LegoOmni::GetTextureContainer ( )

inline

[AI] Returns the global texture container (all loaded textures).

Returns: [AI] Texture container pointer.

Definition at line 359 of file legomain.h.

◆ GetTransitionManager()

MxTransitionManager * LegoOmni::GetTransitionManager ( )

inline

[AI] Returns transition manager for handling UI/game state transitions/fades.

Returns: [AI] Transition manager.

Definition at line 425 of file legomain.h.

◆ GetUserActor()

LegoPathActor * LegoOmni::GetUserActor ( )

inline

[AI] Returns the player-controlled ("user") actor.

Returns: [AI] User path actor pointer.

Definition at line 383 of file legomain.h.

◆ GetVideoManager()

LegoVideoManager * LegoOmni::GetVideoManager ( )

inline

[AI] Returns the active video manager, cast to LegoVideoManager.

Returns: [AI] Video manager.

Definition at line 341 of file legomain.h.

◆ GetViewLODListManager()

ViewLODListManager * LegoOmni::GetViewLODListManager ( )

inline

[AI] Returns the LOD list manager for handling refcounted LOD data in the scene.

Returns: [AI] ViewLODListManager instance.

Definition at line 365 of file legomain.h.

◆ GetWorldAtom()

MxAtomId * LegoOmni::GetWorldAtom ( LegoOmni::World p_id )

[AI] Looks up and returns the AtomId of a world by its enum id.

Parameters

p_id	[AI] World enum id.

Returns: [AI] AtomId pointer or NULL if not found.

Definition at line 491 of file legomain.cpp.

◆ GetWorldId()

LegoOmni::World LegoOmni::GetWorldId ( const char * p_key )

[AI] Looks up a World enum id from its string key.

Parameters

p_key [AI] Key string (case-insensitive).

Returns: [AI] World enum if found, e_undefined otherwise.

Definition at line 505 of file legomain.cpp.

◆ GetWorldList()

LegoWorldList * LegoOmni::GetWorldList ( )

inline

[AI] Returns pointer to world and script registry list.

Returns: [AI] LegoWorldList pointer.

Definition at line 407 of file legomain.h.

◆ GetWorldName()

const char * LegoOmni::GetWorldName ( LegoOmni::World p_id )

[AI] Looks up and returns the registered world key for a world id.

Parameters

p_id	[AI] World enum.

Returns: [AI] String key of world or NULL if not found.

Definition at line 478 of file legomain.cpp.

◆ Init()

void LegoOmni::Init ( )

overridevirtual

[AI] Performs LegoOmni member and subsystem initialization.

[AI]

Reimplemented from MxOmni.

Definition at line 57 of file legomain.cpp.

◆ IsA()

MxBool LegoOmni::IsA ( const char * p_name ) const

inlineoverridevirtual

[AI] Performs runtime type checking, supporting inheritance.

Returns true if input string is "LegoOmni" or matches a parent type.

Parameters

p_name [AI] Class name to test.

Returns: [AI] TRUE if class name matches or inherits from it.

Reimplemented from MxCore.

Definition at line 173 of file legomain.h.

◆ Notify()

MxLong LegoOmni::Notify ( MxParam & p_param )

overridevirtual

[AI] Handles notification messages sent to the engine, including EndAction notifications for quitting, etc.

Parameters

p_param [AI] Parameter describing the notification context.

Returns: [AI] Dispatch result from MxOmni::Notify.

Reimplemented from MxCore.

Definition at line 567 of file legomain.cpp.

◆ NotifyCurrentEntity()

void LegoOmni::NotifyCurrentEntity ( const MxNotificationParam & p_param )

overridevirtual

[AI] Sends notification to the currently active world.

Used for propagating input/events.

Parameters

p_param [AI] Notification parameter struct.

Reimplemented from MxOmni.

Definition at line 449 of file legomain.cpp.

◆ Pause()

void LegoOmni::Pause ( )

overridevirtual

[AI] Pauses the engine/game state and sets busy cursor.

[AI]

Reimplemented from MxOmni.

Definition at line 586 of file legomain.cpp.

◆ RegisterWorlds()

MxResult LegoOmni::RegisterWorlds ( )

[AI] Registers all builtin worlds/scripts into the world's Atom/registry list (m_worlds).

Returns: [AI] SUCCESS if all worlds registered, FAILURE otherwise.

Definition at line 267 of file legomain.cpp.

◆ RemoveWorld()

void LegoOmni::RemoveWorld	(	const MxAtomId &	p_atom,
		MxLong	p_objectId
	)

[AI] Removes worlds by Atom and/or id, deleting matching entries from the world list and freeing resources.

Parameters

p_atom	[AI] AtomId to match, or NULL to match any.
p_objectId	[AI] Object id to match, or -1 for all.

Definition at line 335 of file legomain.cpp.

◆ Resume()

void LegoOmni::Resume ( )

overridevirtual

[AI] Resumes engine/game state and sets default cursor.

[AI]

Reimplemented from MxOmni.

Definition at line 593 of file legomain.cpp.

◆ SetCurrentWorld()

void LegoOmni::SetCurrentWorld ( LegoWorld * p_currentWorld )

inline

[AI] Sets the current world pointer for global context.

Parameters

p_currentWorld [AI] World to use.

Definition at line 455 of file legomain.h.

◆ SetExit()

void LegoOmni::SetExit ( MxBool p_exit )

inline

[AI] Signals the engine to exit/game quit procedure.

Parameters

p_exit [AI] TRUE to begin exit process.

Definition at line 461 of file legomain.h.

◆ SetNavController()

void LegoOmni::SetNavController ( LegoNavController * p_navController )

inline

[AI] Sets the navigation controller.

Parameters

p_navController [AI] Nav controller to use.

Definition at line 443 of file legomain.h.

◆ SetUnknown13c()

void LegoOmni::SetUnknown13c ( MxBool p_unk0x13c )

inline

[AI] Sets the unknown0x13c flag (purpose not fully documented in reverse).

[AI]

Parameters

p_unk0x13c [AI] Value to set.

Definition at line 474 of file legomain.h.

◆ SetUserActor()

void LegoOmni::SetUserActor ( LegoPathActor * p_userActor )

inline

[AI] Sets the user actor pointer (player).

Parameters

p_userActor [AI] User actor to use.

Definition at line 449 of file legomain.h.

◆ Start()

MxResult LegoOmni::Start ( MxDSAction * p_dsAction )

overridevirtual

[AI] Begins executing the specified DSAction/script in the context of the current world/state.

Parameters

p_dsAction [AI] DSAction instance indicating the next action sequence/script.

Returns: [AI] Start result status.

Reimplemented from MxOmni.

Definition at line 548 of file legomain.cpp.

◆ StartActionIfUnknown0x13c()

MxResult LegoOmni::StartActionIfUnknown0x13c ( MxDSAction & p_dsAction )

inline

[AI] Starts action if the unknown0x13c member is set; otherwise returns success.

Helper for rare logic.

Parameters

p_dsAction [AI] Action to start.

Returns: [AI] Start result or SUCCESS if not started.

Definition at line 468 of file legomain.h.

Member Data Documentation

◆ m_unk0x13c

MxBool LegoOmni::m_unk0x13c

[AI] Unknown flag used in rare start-action cases. [AI]

Definition at line 504 of file legomain.h.

The documentation for this class was generated from the following files:

Classes

Public Types

Public Member Functions

Static Public Member Functions

Public Attributes

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ anonymous enum

◆ World

Constructor & Destructor Documentation

◆ LegoOmni()

◆ ~LegoOmni()

Member Function Documentation

◆ AddToWorld()

◆ AddWorld()

◆ ClassName()

◆ CloseMainWindow()

◆ Create()

◆ CreateBackgroundAudio()

◆ CreateInstance()

◆ DeleteAction()

◆ DeleteObject()

◆ DeleteWorld()

◆ Destroy()

◆ DoesEntityExist()

◆ FindROI()

◆ FindWorld()

◆ FUN_1005b4f0()

◆ GetAnimationManager()

◆ GetBackgroundAudioManager()

◆ GetBuildingManager()

◆ GetCharacterManager()

◆ GetCurrentAction()

◆ GetCurrentWorld()

◆ GetCurrPathInfo()

◆ GetGameState()

◆ GetInputManager()

◆ GetInstance()

◆ GetNavController()

◆ GetPlantManager()

◆ GetSoundManager()

◆ GetTextureContainer()

◆ GetTransitionManager()

◆ GetUserActor()

◆ GetVideoManager()

◆ GetViewLODListManager()

◆ GetWorldAtom()

◆ GetWorldId()

◆ GetWorldList()

◆ GetWorldName()

◆ Init()

◆ IsA()

◆ Notify()

◆ NotifyCurrentEntity()

◆ Pause()

◆ RegisterWorlds()

◆ RemoveWorld()

◆ Resume()

◆ SetCurrentWorld()

◆ SetExit()

◆ SetNavController()

◆ SetUnknown13c()

◆ SetUserActor()

◆ Start()

◆ StartActionIfUnknown0x13c()

Member Data Documentation

◆ m_unk0x13c
